AVANCER2

AVANCER2 is an automatic double turret slitter with four rewinding shafts designed for increased productivity and low production downtime. The slitter is built according to traditional JURMET solid and robust construction standards.

  • 1000-1800mm (39.4"-70.7")
    Web width
  • 1100-1500mm (43.3"-59.1")
    Unwind roll diameter
  • 610mm (24")
    Max. rewind diameter
  • 700m/min. (2297 ft/min.)
    Speed

AVANCER2

AVANCER2 - duplex turret slitter with separate unwinder

AVANCER2 is an automatic double turret slitter with four rewinding shafts and a separate unwind station designed for increased productivity and low production downtime. The slitter is built according to traditional JURMET solid and robust construction standards. Numerous proven solutions applied in AVANCER2 slitter are designed to facilitate operation features and maintain the high degree of flexibility.

TECHNICAL DATA

Width of material
1000/1300/1600/1800mm (39.4"/51.2"/63"/70.7")
Unwind diameter
1100/1300/1500mm (43.3"/51.2"/59.1")
Rewind diameter
610mm (24")
Max. mechanical speed
700m/min. (2297 ft/min.)
Weight of parent roll
2500 kg (5512 lbs)
Min. slitting width
25mm/1" (50mm/2" as standard)
Core ID
70mm, 3”, 120mm, 150mm, 6”
Converted material
printed / unprinted foil (PE,PP,PA,PET and other),metalised foil, laminated, shrink film, label stock film, paratransmission film, aluminium, paper.
Application
packaging for food industry, flexo printing houses, health care materials and pharma materials
